Name	Qualiton APX 200 Tube Power Amplifier
Rated output power	2 x 100 W, stereo
Total harmonic distortion	< 1% (f = 1 kHz, rated output power)
Frequency response	15 Hz - 100 kHz (-3 dB, rated output power)
Input sensitivity	665 mV, unbalanced input
Number of input ports	1 unbalanced input per channel
Number of output ports	1 output terminal pair per channel
Gain	+32.5 dB (8 Ohm); +29.5 dB (4 Ohm)
Input impedance	10 kOhm
Nominal load impedance	4 Ohm and 8 Ohm
Output polarity	non-inverting
Signal-to-noise ratio	> 101 dB
Power requirements	520 W
Tubes required	4 x KT90; 2 x 6N23P; 2 x 12AX7LP
Weight	29.6 kg
Dimensions	43 x 18,5 x 40 cm



Name	Qualiton APX 200 Tube Power Amplifier
額定輸出功率	2 x 100 W, stereo
總諧波失真	< 1% (f = 1 kHz, rated output power)
頻率響應	15 Hz - 100 kHz (-3 dB, rated output power)
輸入靈敏度	665 mV, unbalanced input
輸入端口數（每個通道）	1 unbalanced input per channel
輸出通道數（每個通道）	1 output terminal pair per channel
增益	+32.5 dB (8 Ohm); +29.5 dB (4 Ohm)
輸入阻抗	10 kOhm
額定負載阻抗	4 Ohm and 8 Ohm
輸出極性	non-inverting
信噪比	> 101 dB
功率需求	520 W
所需管子	4 x KT90; 2 x 6N23P; 2 x 12AX7LP
重量	29.6 kg
尺寸	43 x 18,5 x 40 cm
